Fasteners
Bugle Head Exterior Structural Wood Screws
WSBH
Reference Series: -- --
The WSBH is a multi-purpose structural wood screw ideal for a low profile appearance in wood-to-wood connections. This structural wood screw allows the Pro Contractor or DIYer to drive the head flush or countersink it below the wood surface. The WSBH is easy to install and a high strength alternative to traditional lags, bolts and pole barn nails.
Features & Benefits:
• No predrilling
• Comparable to 1/2" lag screw
• Low profile head style can be driven flush or countersunk
• Type 17 point reduces installation torque and splitting
• T30* drive elimates cam-out
• Length identification stamps on all heads
•1/4" shank diameter, 0.46" head diameter
* T30 is a trademark of Acument
Features & Benefits:
• No predrilling
• Comparable to 1/2" lag screw
• Low profile head style can be driven flush or countersunk
• Type 17 point reduces installation torque and splitting
• T30* drive elimates cam-out
• Length identification stamps on all heads
•1/4" shank diameter, 0.46" head diameter
* T30 is a trademark of Acument
Materials: 1/4" diameter Grade 5 steel
Finish: Exterior Coat
Code Reports:
View Code Report Table
Resources
MiTek Product CatalogTechnical Bulletins
Installation
- For best results, install the MiTek Bugle Head using a high torque, 1/2″ variable speed drill.
- Bring the head flush to the surface of the wood or countersink.
Need Help or Have a Question? Contact Customer Service or Call 800-328-5934
WSBH Bugle Head Structural Screw
